Features:
MING hot dipped malleable iron fitting are each individually pressure testes to ensure pin hole free quality. Each fitting is coated with a light oil to prevent corrosion on the threads which conforms to ISO 7-1 (BSP Standard) and ensure a perfect seal for the fittings lifetime.

My Pressure Conversion
=
Powered by CalculateStuff.com

Product Dimensions

Dimenstions Table

Item CodeSizeMetric ConversionA
924/00151/2"15mm27mm
924/00203/4"20mm32mm
924/00251"25mm37mm
924/00321 1/4"32mm44.5mm
924/00401 1/2"40mm49mm
924/00502"50mm57mm
924/00652 1/2"65mm68.5mm
924/00803"80mm77.5mm
924/01004"100mm96.5mm

Technical Data

Maximum Pressure: 16 BAR (230PSI) (1.6MPA)
Maximum Temperature: 200°C (392°F)
Tensile Strength: 330MPA
Hardness: HB150 (Brinell)
Elongation Rate: 8%
Suitable Applications: Water, Oil, Gas, Petro-Chemical
Material: Hot Dipped Malleable Iron
